PIDSMaker

The first framework designed to build and experiment with provenance-based intrusion detection systems (PIDSs) using deep learning architectures. It provides a single codebase to run most recent state-of-the-art systems and easily customize them to develop new variants.

Purpose

PIDSMaker is an open-source framework designed to be collaboratively developed and maintained by the security research community. It was born out of the observation that recent papers in top-tier security venues often evaluate on the same datasets but differ in labeling strategies and in the implementation of baseline methods.

Until now, no standardized open-source framework has existed to facilitate fair comparisons. PIDSMaker addresses this gap by providing the following key features:

1. Consistent evaluation and benchmarking of SOTA baselines using unified datasets, labeling strategies, and reference implementations.
2. A modular testbed of existing components extracted from published systems, enabling experimentation and the discovery of improved variants.
3. A centralized repository where authors can contribute and share code for new systems, ensuring fair and reproducible benchmarking.

What is system provenance?

System provenance is a detailed record of all activities occurring on a computer system. Operating systems like Linux and Windows can be configured to capture these events through audit frameworks (e.g., Linux Audit, ETW on Windows).

Provenance data captures:

• Process execution: Which programs ran, with what arguments
• File operations: Reads, writes, creates, deletes
• Network activity: Connections, data transfers
• Inter-process communication: Pipes, signals, shared memory

Provenance graphs

Raw provenance logs are transformed into a provenance graph—a directed graph where:

Element	Description	Examples
Nodes	System entities	Processes, files, network sockets
Edges	Interactions between entities	Process reads file, process connects to socket

┌─────────┐   READ    ┌─────────┐
│ Process │ ────────▶ │  File   │
│  nginx  │           │ config  │
└─────────┘           └─────────┘
     │
     │ CONNECT
     ▼
┌─────────┐
│ Socket  │
│ :8080   │
└─────────┘

Node types

PIDSMaker uses three primary node types:

Type	Description	Attributes
subject	Processes/threads	Command line, executable path
file	Files and directories	File path
netflow	Network connections	IP address, port

Edge types

Edges represent system calls or events. PIDSMaker uses 10 edge types:

Edge Type	Description
EVENT_READ	Process reads from file
EVENT_WRITE	Process writes to file
EVENT_OPEN	Process opens file
EVENT_EXECUTE	Process executes file
EVENT_CONNECT	Process connects to network
EVENT_RECVFROM	Process receives network data
EVENT_RECVMSG	Process receives network message
EVENT_SENDTO	Process sends network data
EVENT_SENDMSG	Process sends network message
EVENT_CLONE	Process creates child process (fork)

How PIDSs detect attacks

PIDSs use self-supervised learning to detect intrusions:

1. Training phase (benign data only)

┌─────────────────────────────────────────────────────────┐
│                    Training Pipeline                    │
├─────────────────────────────────────────────────────────┤
│  Benign        Graph           GNN          Learn       │
│  Provenance ─▶ Construction ─▶ Encoder ─▶   Normal      │
│  Logs                                       Behavior    │
└─────────────────────────────────────────────────────────┘

The model learns patterns of normal system behavior: - Which processes typically access which files - Normal network communication patterns - Typical sequences of system calls

2. Detection phase (test data with attacks)

┌─────────────────────────────────────────────────────────┐
│                   Detection Pipeline                    │
├─────────────────────────────────────────────────────────┤
│  Test          Compute         Compare to    Flag       │
│  Provenance ─▶ Predictions ─▶  Threshold  ─▶ Anomalies  │
└─────────────────────────────────────────────────────────┘

At inference time: 1. The trained model makes predictions about system behavior 2. Prediction errors (reconstruction loss) indicate anomalies 3. Entities with errors above a threshold are flagged as malicious

Graph Neural Networks (GNNs)

PIDSMaker mainly uses Graph Neural Networks to learn from provenance graphs. GNNs are neural networks designed to operate on graph-structured data.

Message passing

GNNs work through message passing: each node aggregates information from its neighbors to update its representation.

     Round 1                    Round 2
  ┌───┐                      ┌───┐
  │ A │◄── neighbor info     │ A │◄── 2-hop info
  └───┘                      └───┘
   ▲ ▲                        ▲ ▲
  ╱   ╲                      ╱   ╲
┌───┐ ┌───┐               ┌───┐ ┌───┐
│ B │ │ C │               │ B │ │ C │
└───┘ └───┘               └───┘ └───┘

After multiple rounds, each node's embedding captures its local neighborhood structure.

PIDSMaker provides several GNN encoders (GraphSAGE, GAT, TGN, etc.) and self-supervised objectives (edge type prediction, node type prediction, feature reconstruction, etc.). See the Arguments section for the full list of available components.

The 7-stage pipeline

PIDSMaker structures detection into seven stages, from graph construction to evaluation and optional triage. See the Pipeline page for detailed documentation of each stage.

Citing the Framework

If you use this framework, please cite the following paper:

@inproceedings{bilot2025simpler,
    title={{Sometimes Simpler is Better: A Comprehensive Analysis of State-of-the-Art Provenance-Based Intrusion Detection Systems}},
    author={Bilot, Tristan and Jiang, Baoxiang and  Li, Zefeng and  El Madhoun, Nour and Al Agha, Khaldoun and Zouaoui, Anis and Pasquier, Thomas},
    booktitle={Security Symposium (USENIX Sec'25)},
    year={2025},
    organization={USENIX}
}
